Description
Bands
Test Value (Unit: mA)
Notes/Configuration
Typical
TD-SCDMA
TD-SCDMA
bands
53
Module is powered up.
DRX cycle=8 (2.56s)
Module is registered on the
network.
USB is in active.
HSPA+/WCDMA
UMTS bands
52
Module is powered up.
DRX cycle=7 (1.28s)
Module is registered on the
network, no data is transmitted.
USB is in active.
GPRS/EDGE
GSM bands
52
Module is powered up.
MFRMS=5 (1.175s)
Module is registered on the
network, no data is transmitted.
USB is in active.
Table 5-6 Averaged standby DC power consumption of ME909s-120 Mini PCIe module
Description
Bands
Test Value (Unit: mA)
Notes/Configuration
Typical
Sleep
LTE
LTE bands
2.2
Module is powered up.
DRX cycle=8 (2.56s)
Module is registered on the
network.
USB is in suspend.
HSPA+/WCDMA
UMTS bands
1.3
Module is powered up.
DRX cycle=7 (1.28s)
Module is registered on the
network.
USB is in suspend.
GPRS/EDGE
GSM bands
1.6
Module is powered up.
MFRMS=5 (1.175s)
Module is registered on the
network.
USB is in suspend.
