Huawei ME909s Series - Mechanical Specifications; Dimensions

HUAWEI ME909s Series LTE Mini PCIe Module
Hardware Guide
Mechanical Specifications
Issue 02 (2016-09-07)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
60
6 Mechanical Specifications
6.1 About This Chapter
This chapter mainly describes mechanical specifications of ME909s Mini PCIe module,
including:

Dimensions

Packaging

Specification Selection for Fasteners

Antenna Plug

Thermal Design Guide
6.2 Dimensions
Figure 6-1 shows the dimensions in detail.
