Huawei NE40E-X1 User Manual

Attribute Value
Maximum output
power
-2.5 dBm -3.0 dBm 3.0 dBm 1.0 dBm 5.0 dBm 5.0 dBm
Receiving
sensitivity
-17.0
dBm
-20.0
dBm
-22.5
dBm
-21.0
dBm
-23.0
dBm
-30.0
dBm
Overload optical
power
0 dBm -3.0 dBm -3.0 dBm -3.0 dBm -3.0
dBm
-9.0 dBm
Optical fiber type Multimo
de
Single-
mode
Single-
mode
Single-
mode
Single-
mode
Single-
mode
Table 3-12 Attributes of the 1000M colored optical module
Attribute Value
Transmission
distance
70 km
( 43.50
mi. )
70 km
( 43.50
mi. )
70 km
( 43.50
mi. )
70 km
( 43.50
mi. )
70 km
( 43.50
mi. )
70 km
( 43.5
0 mi. )
70 km
( 43.5
0 mi. )
70 km
( 43.5
0 mi. )
Center
wavelength
1470
nm
1490
nm
1510
nm
1530
nm
1550
nm
1570
nm
1590
nm
1610
nm
Minimum
output power
0 dBm 0 dBm 0 dBm 0 dBm 0 dBm 0 dBm 0
dBm
0 dBm
Maximum
output power
5 dBm 5 dBm 5 dBm 5 dBm 5 dBm 5 dBm 5
dBm
5 dBm
Receiving
sensitivity
-23.0
dBm
-23.0
dBm
-23.0
dBm
-23.0
dBm
-23.0
dBm
-23.0
dBm
-23.0
dBm
-23.0
dBm
Overload
optical power
0 dBm 0 dBm 0 dBm 0 dBm 0 dBm 0 dBm 0
dBm
0 dBm
Optical fiber
type
Single
-mode
Single-
mode
Single-
mode
Single-
mode
Single-
mode
Single
-mode
Singl
e-
mode
Single
-mode
Specifications
Table 3-13 lists the specifications of the specifications of the8-Port 100/1000Base-X-SFP High-
speed Interface Card A (HIC, Supporting 1588v2) .
