Checking the Installation
8
Check Before Power-on
If the power supply voltage does not meet requirements, do not power on
the device.
Check whether fixed optical attenuators have been added in accordance
with corresponding configuration rules.
Check whether the fuse capacity of the external power supply meets re-
quirements.
Check whether the external power supply voltage is normal.
CAUTION
STAT
Indicator Abnormal State Possible Cause Handling Procedure
Steady red
Steady o
Signals on an
optical port are
lost.
The corre-
sponding
module cannot
be detected.
1. Power on the peer chassis.
2. Check the peer board and
ensure that the transmit opti-
cal power of the board is
normal.
3. Check that fiber connections
are correct.
4. If there is no fixed optical
attenuator at the optical port,
check the fiber attenuation,
clean the fiber connector, and
replace damaged fibers until
the indicator turns green.
If the chassis is powered on
but all the indicators on the
board are o, contact software
commissioning engineers to
replace the board.
Before performing a power-on check,
turn o all the switches on the device
and external power supply system.
WARNING
The following table describes the
states of indicators when the device
is operating properly.
Hardware Module
Steady greenPower module
Steady green
Steady green
Steady green
Steady green
Steady green
Fan module
Main control board
Interface board
PWR
FAN
STAT
PROG
STAT
L/A
Indicator State
Power-on Check
If board indicators are in speci-
fied abnormal states after you
power on the device, handle
the abnormalities onsite.
For more information about device indi-
cators, see in the
corresponding product documentation.
NOTE
HardwareDescription
