Huawei P20 User Manual

AM
FM
Connect your Phone with your car to share apps
Use MirrorLink to connect your Phone to your car:
1 Enable the MirrorLink function on your in-car display before attempting to connect your device for
the rst time. Please ensure that your Phone is connected to the Internet in order to download the
required MirrorLink certicates.
2 Connect your Phone and car using Bluetooth. From the Bluetooth settings page on your Phone, go
to Help > Vehicle to view instructions on how to connect.
3 Use a USB data cable to connect your Phone to your car. When the Disclaimer dialogue box
appears on your Phone, touch Agree, wait until the Terms of Service dialogue appears, and then
touch Agree, Phone again to connect to the car using MirrorLink.
If a prompt is not shown on your Phone after you connect it to your car, your car model may
not support MirrorLink or there could be an issue with your car's rmware. Please update your
car's rmware and try again.
4 If you are connecting your Phone to the car for the rst time, wait until the prompt is shown,
remove and reinsert the USB data cable as instructed, and then proceed with step 3. Your Phone
should then connect to your car.
After establishing a MirrorLink connection, you can't adjust the Phone volume, but you can adjust
the car volume. Your Phone screen will switch off automatically, but will not lock.
Disconnect your Phone from your car: Disconnect the USB data cable that connects your Phone to
your car to terminate the MirrorLink connection. After disconnecting, your Phone's screen will turn on
and you will be able to adjust the Phone volume again.
Utilities
87

Huawei P20 Specifications

General

Panel type	TFT
Screen shape	Flat
Pixel density	428 ppi
Second display	No
Display diagonal	5.8 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	2244 x 1080 pixels
Native aspect ratio	19:9
Rounded display corners	Yes
Display number of colors	16 million colors
Processor cores	4
Processor family	Hi-Silicon
Processor frequency	2.36 GHz
Coprocessor frequency	1.8 GHz
Processor architecture	ARM Cortex-A73
Coprocessor architecture	ARM Cortex-A53
RAM capacity	4 GB
Compatible memory cards	Not supported
Internal storage capacity	128 GB
Flash type	LED
Rear camera type	Dual camera
Front camera type	Single camera
Video recording modes	1080p, 2160p
Rear camera aperture number	1.8
Front camera aperture number	2
Rear camera resolution (numeric)	12 MP
Front camera resolution (numeric)	24 MP
Second rear camera aperture number	1.6
Second rear camera resolution (numeric)	20 MP
4G standard	LTE
2G standards	GSM
3G standards	WCDMA
SIM card type	NanoSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Bluetooth profiles	A2DP, APT-X
SIM card capability	-
Mobile network generation	4G
Subscription type	No subscription
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
HDMI ports quantity	0
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Form factor	Bar
Product color	Blue
Themes	Wallpapers
Graphics card	Mali-G72 MP12
Personalization	Icons, Menu, Shortcuts
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes
Speakers	stereo
Audio formats supported	3GP, AAC, APE, FLAC, MIDI, MP3, OGG, WAV
Video formats supported	3G2, 3GP, ASF, H.264, MKV, MP4, WEBM
Platform	Android
Operating system installed	Android 8.1
Talk time (3G)	- h
Battery capacity	3400 mAh
Battery recharge time	1.5 h
Interface adapters included	USB Type-C - 3.5mm

Weight and Dimensions

Depth	7.65 mm
Width	70.8 mm
Height	149.1 mm
Weight	165 g
