Huawei PDC-0091V2ACIOA Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
66
Figure 3-47 RH2288V2 server
The RH2288V2 has the following features:
⚫
It has powerful computing and storage capacity and scalability.
⚫
It can be flexibly configured with value-added components and has multiple functions.
Table 3-37 RH2288V2 specifications
Item
Specifications
Structural
design
2 U, H x W x D: 87.5 mm x 447 mm x 740 mm
Can be installed in a standard 19-inch cabinet with the depth equal to or
greater than 1000 mm
Mai
n
boar
d
CPU
One or two
CPU
model
Supports Intel
®
Xeon
®
E5-2600 (Romely-EP) series 4C/6C/8C processors
with a maximum power of 135 W. The maximum main frequency is 3.3
GHz, and a single CPU provides the L3 cache of 20 MB.
Mem
ory
Provides 24 DIMM slots, supports RDIMM/LRDIMM memory of DDR3
with a maximum capacity of 768 GB.
Hard
drive
Supports eight hot-swappable 6 Gbit/s SAS/SATA/SSD hard drives of 2.5
inches, or twelve hot-swappable 6 Gbit/s SAS/SATA hard drives of 3.5
inches and two hot-swappable 6 Gbit/s SAS/SATA/SSD hard drives of 2.5
inches.
Expan
sion
Provides six expansion slots for PCIe 3.0 cards: one for PCIe3.0X16, four
for PCIe3.0X8, and one for RAID.
3.4.3 ECC800
The ECC800 controller is mainly used for device and environment monitoring in a modular
data center. It consists of two power supply units (PSUs) and one ECC800 monitoring
module.
Figure 3-48 and Figure 3-49 show an ECC800 controller.
