Huawei PDC-0091V2ACIOA Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
83
3.4.7.2 Aisle Access Control
The aisle access control system applies to the aisle containment. It provides monitoring and
data for devices and personnel moving into or out of the aisle containment. It can support the
fingerprint and card reader with a password keyboard, fingerprint and card reader, and card
reader with a password keyboard.
Fingerprint and Card Reader with a Password Keyboard
Figure 3-55 shows a fingerprint and card reader with a password keyboard.
Figure 3-55 Fingerprint and card reader with a password keyboard
Table 3-52 lists the specifications of a fingerprint and card reader with a password keyboard.
Table 3-52 Specifications of a fingerprint and card reader with a password keyboard
Item
Specifications
Dimensions (L x W x H)
156 mm x 53 mmx38mm
Operating voltage
Range: 10.8–13.2 V DC, rated voltage: 12 V DC
Operating current
Static standby current < 200 mA, dynamic card swiping
operating current < 300 mA, minimum input current 500
mA at 12 V DC
Supported card
Mifare-1 S50 IC card
Authorized storage
A maximum of 3000 authorized users, a maximum of
6000 fingerprints
Communication mode
RS485 port, Wiegand port
