Huawei S5700 Series Hardware Description

Table 3-62 Technical specifications
Item Description
Memory (RAM) 256 MB
Flash 200 MB
Mean time between
failures (MTBF)
45.91 years
Mean time to repair
(MTTR)
2 hours
Availability > 0.99999
Service port surge
protection
Common mode: ±6 kV
Power supply surge
protection
±6 kV in differential mode, ±6 kV in common mode
Dimensions (W x
D x H)
442.0 mm x 310.0 mm x 43.6 mm (17.4 in. x 12.2 in. x 1.72 in.)
Weight ≤ 5 kg (11.02 lb)
Stack ports Two uplink 1000Base-X optical ports (non-combo ports)
RPS Supported
PoE Supported
Rated voltage range 100 V AC to 240 V AC, 50/60 Hz
Maximum voltage
range
90 V AC to 264 V AC, 47 Hz to 63 Hz
Maximum power
consumption
(100% throughput,
100% PoE loads,
full speed of fans)
238.7 W (system power consumption: 53.9 W, PoE: 184.8 W)
Operating
temperature
0°C to 50°C (32°F to 122°F) at an altitude of 0-1800 m (0-5096 ft.)
NOTE
When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating
temperature reduces by 1°C (1.8°F) every time the altitude increases by 220
m (722 ft.).
Storage
temperature
-40°C to +70°C (-40°F to +158°F)
Noise under normal
temperature (27°C,
sound power)
< 45 dBA
Relative humidity 5% to 95%, noncondensing
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
131

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
