Page #41 background imageLoading...
Page #41 background image
Type Model Description
ES5D21X02T01 2-port 10GBASE-T RJ45
interface card, used in S5720-EI
series
ES5D21VST000 2-port QSFP+ dedicated stack
interface card, used in S5720-EI
series
2.4 Components Available in V200R007C10 Version
Available Models
Table 2-10 S5700 models available in V200R007C10
Series
Model Maximum Number of Service Ports
S5720-HI S5720-56C-HI-AC 56 total:
48 Ethernet 10/100/1000 ports, 4 10-Gig SFP
+ (10GE/GE auto-sensing), 4 10-Gig SFP+ ports on
the rear card
S5720-56C-PWR-
HI-AC
56 total:
48 Ethernet 10/100/1000 PoE+ ports, 4 10-Gig SFP
+ (10GE/GE auto-sensing), 4 10-Gig SFP+ ports on
the rear card
S5720-32C-HI-24S-
AC
32 total:
24 Gig SFP (8 of which are dual-purpose
10/100/1000BASE-T or SFP), 4 10-Gig SFP
+ (10GE/GE auto-sensing), 4 10-Gig SFP+ ports on
the rear card
Available Power Modules
Table 2-11 S5700 power modules available in V200R007C10
Power Module
Type
Power Module Power Description
AC power module PAC-600WA-B 600 W AC power module
DC power module PDC-350WA-B 350 W DC power module
AC PoE power
module
W2PSA1150 1150 W AC PoE power module
S5700 Series Ethernet Switches
Hardware Description
2 Version Support for Components
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
