Numbe
r
Indicator/
Button
Color Description
If you are changing the indicator mode:
l Off: The stack mode is not selected.
l Steady on: The switch is a standby or
slave switch in a stack, and the service
port indicators show the stack ID of
the switch.
l Blinking: The switch is the master
switch in a stack or a standalone
switch, and the service port indicators
show the stack ID of the master
switch.
After 45 seconds, the service port
indicators automatically restore to the
status mode.
7 MODE: mode
switch button
-
l When you press this button once, the
service port indicators change to the
speed mode and show the speed of
each service port.
l When you press this button a second
time, the service port indicators
change to the stack mode and show
the stack ID of the local switch.
l When you press this button a third
time, the service port indicators
restore to the default mode, and the
STAT indicator turns green.
If you do not press the MODE button
within 45 seconds, the service port
indicators restore to the default mode. In
this case, the STAT indicator is steady
green, the SPED indicator is off, and the
STCK indicator is off or blinking green.
