Display Mode Color Description
Yellow
l Steady on: The PoE function is
disabled on the port.
l Blinking: A PoE fault has occurred.
For example, an incompatible PD is
connected to the port.
Green and
yellow
Blinking green and yellow alternately:
The port cannot provide power to a PD.
The possible reasons include:
l The power of the PD exceeds the
maximum power or power threshold
of the port.
l The total power consumption of PDs
has reached the maximum power of
the switch.
l The manual power management mode
is used and the port is not enabled to
provide power to the PD.
Stack Green
l Off: Port indicators do not show the
stack ID of the switch.
l If the indicator is steady on, the
switch is not a master switch:
– If the indicator of a port is steady
on, the number of this port is the
stack ID of the switch.
– If the first nine port indicators are
steady on, the stack ID of the
switch is 0.
l If the indicator is blinking, the switch
is a master switch:
– If the indicator of a port is
blinking, the number of this port is
the stack ID of the switch.
– If the first nine port indicators are
blinking, the stack ID of the switch
is 0.
Power Supply Configuration
The S5700-28X-PWR-LI-AC has a built-in power module and does not support pluggable
power modules. It can provide PoE power supply and connect to an RPS1800 power supply
for power redundancy. Table 3-81 lists its power supply configurations.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
156
