Table 3-131 Description of service port indicators in different modes (one indicator for each
port)
Display Mode Color Description
Status Green
l Off: The port is not connected or has
been shut down.
l Steady on: The port is connected.
l Blinking: The port is sending or
receiving data.
Speed Green
l Off: The port is not connected or has
been shut down.
l Steady on:
10M/100M/1000M port: The port is
operating at 10/100 Mbit/s.
1000M/10GE port: The port is
operating at 1000 Mbit/s.
l Blinking:
10M/100M/1000M port: The port is
operating at 1000 Mbit/s.
1000M/10GE port: The port is
operating at 10 Gbit/s.
Stack Green
l Off: Port indicators do not show the
stack ID of the switch.
l If the indicator is steady on, the
switch is not a master switch:
– If the indicator of a port is steady
on, the number of this port is the
stack ID of the switch.
– If the first nine port indicators are
steady on, the stack ID of the
switch is 0.
l If the indicator is blinking, the switch
is a master switch:
– If the indicator of a port is
blinking, the number of this port is
the stack ID of the switch.
– If the first nine port indicators are
blinking, the stack ID of the switch
is 0.
Power Supply Configuration
The S5700-52X-LI-48CS-AC has a built-in power module and does not support pluggable
power modules. It can connect to an RPS1800 power supply for power redundancy.
