Huawei S5700 Series Hardware Description

Number Indicator/
Button
Color Description
9 Console
indicator
Green
l Off: The console port is not active,
and the Mini USB port is active.
l Steady on (default): The console port
is active.
When this LED is on, the Mini USB port
indicator is off.
Table 3-138 Description of service port indicators in different modes
Display Mode
Color Description
Status Green
l Off: The port is not connected or has
been shut down.
l Steady on: The port is connected.
l Blinking: The port is sending or
receiving data.
Speed Green
l Off: The port is not connected or has
been shut down.
l Steady on:
10M/100M/1000M port: The port is
operating at 10/100 Mbit/s.
1000M/10GE port: The port is
operating at 1000 Mbit/s.
l Blinking:
10M/100M/1000M port: The port is
operating at 1000 Mbit/s.
1000M/10GE port: The port is
operating at 10 Gbit/s.
Power Supply Configuration
The S5700S-28P-LI-AC has a built-in power module and does not support pluggable power
modules. It can connect to an RPS1800 power supply for power redundancy.
Figure 3-52 shows the power supply mode of a built-in AC power module. The built-in AC
power module (PWR) receives power from an external power source and provides a 12 V
output to the chassis.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
220

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
