Huawei S5700 Series Hardware Description

Series Model Maximum Number of Service Ports
S5700-52C-PWR-
EI
52 total:
48 Ethernet 10/100/1000 PoE+ ports, 4 ports on the
front card
S5710-HI S5710-108C-PWR-
HI
108 total:
48 Ethernet 10/100/1000 PoE+ ports, 8 10-Gig SFP
+ (10GE/GE auto-sensing), 48 ports on the three
front cards, and 4 ports on one rear card
Available Power Modules
Table 2-20 S5700 power modules available in V200R005C03
Power
Module
Type
Power Module Power Description
AC power
module
LS5M100PWA00 150 W AC power module (purplish grey)
PAC-350WA-B 350 W AC power module
DC power
module
LS5M100PWD00 150 W DC power module (purplish grey)
AC PoE
power
module
W0PSA2500 250 W AC PoE power module
W0PSA5000 500 W AC PoE power module
W2PSA1150 1150 W AC PoE power module
Available Cards
Table 2-21 S5700 cards available in V200R005C03
Card Type
Card Name Card Description
Front card ES5D000X2S00 2-port 10GE SFP+ front optical interface card
ES5D000X4S01 4-port 10GE SFP+ front optical interface card
ES5D000G4S01 4-port GE optical front interface card
ES5D21G16S00 16-port GE SFP front optical interface card
ES5D21G16T00 16-port GE front electrical interface card
Rear card ES5D00ETPC00 Stack rear card
ES5D00ETPB00 Extended rear card
S5700 Series Ethernet Switches
Hardware Description
2 Version Support for Components
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
37

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
