Huawei S5700 Series Hardware Description

Series Model Maximum Number of Service Ports
S5710-28C-PWR-
EI-AC
44 total:
24 Ethernet 10/100/1000 PoE+ ports (4 of which are
dual-purpose 10/100/1000 or SFP), 4 10-Gig SFP
+ (10GE/GE auto-sensing), and 16 ports on the two
rear cards
S5710-52C-PWR-
EI-AC
68 total:
48 Ethernet 10/100/1000 PoE+ ports, 4 10-Gig SFP
+ (10GE/GE auto-sensing), and 16 ports on the two
rear cards
S5710-52C-PWR-
EI
68 total:
48 Ethernet 10/100/1000 PoE+ ports, 4 10-Gig SFP
+ (10GE/GE auto-sensing), and 16 ports on the two
rear cards
S5710-HI S5710-108C-PWR-
HI
108 total:
48 Ethernet 10/100/1000 PoE+ ports, 8 10-Gig SFP
+ (10GE/GE auto-sensing), 48 ports on the three
front cards, and 4 ports on one rear card
Available Power Modules
Table 2-23 S5700 power modules available in V200R005C02
Power
Module
Type
Power Module Power Description
AC power
module
LS5M100PWA00 150 W AC power module (purplish grey)
ES0W2PSA0150 150 W AC power module (black)
W0PSA1701 170 W AC power module
PAC-350WA-B 350 W AC power module
DC power
module
LS5M100PWD00 150 W DC power module (purplish grey)
ES0W2PSD0150 150 W DC power module (black)
ES5M0PSD1700 170 W DC power module
AC PoE
power
module
W0PSA2500 250 W AC PoE power module
W0PSA5000 500 W AC PoE power module
W2PSA0580 580 W AC PoE power module
W2PSA1150 1150 W AC PoE power module
S5700 Series Ethernet Switches
Hardware Description
2 Version Support for Components
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
40

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
