Huawei S5700 Series Hardware Description

Power
Module
Type
Power Module Power Description
ES0W2PSA0150 150 W AC power module (black)
W0PSA1701 170 W AC power module
DC power
module
LS5M100PWD00 150 W DC power module (purplish grey)
ES0W2PSD0150 150 W DC power module (black)
ES5M0PSD1700 170 W DC power module
RPS power
supply
RPS1800 RPS1800
LS5W2PSA0870 870 W PoE power module
AC PoE
power
module
W0PSA2500 250 W AC PoE power module
W0PSA5000 500 W AC PoE power module
W2PSA0580
*
580 W AC PoE power module
W2PSA1150
*
1150 W AC PoE power module
Available Cards
Table 2-38 S5700 cards available in V200R002C00
Card Type
Card Name Card Description
Front card ES5D000X2S00 2-port 10GE SFP+ optical interface card
ES5D000X4S01 4-port 10GE SFP+ optical interface card
ES5D000G4S01 4-port GE optical interface card
ES5D00G4SA01 4-port GE optical interface card
ES5D00X2SA00 2-port GE SFP or 10GE SFP+ optical interface card
ES5D00X4SA00 4-port GE SFP or 10GE SFP+ optical interface card
ES5D00G4SC00 4-port GE SFP optical interface card
Rear card ES5D21G08S00 8-port GE SFP optical interface card
ES5D21G08T00 8-port GE electrical interface card
ES5D21X02S00 2-port GE SFP or 10GE SFP+ optical interface card
ES5D00ETPC00 Stack card
ES5D00ETPB00 Extended channel card
S5700 Series Ethernet Switches
Hardware Description
2 Version Support for Components
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
59

Huawei S5700 Series Specifications

General

Model	S5700 Series
Category	Switch
Power Supply	AC or DC
Fixed GE Ports	24/48 (depending on model)
PoE	Available on some models
Routing Protocols	RIP, OSPF, BGP, IS-IS
Management	SNMP, RMON, Web-based, CLI
Operating Temperature	0°C to 45°C
VLAN	4094
Dimensions (W x D x H)	442.0 mm x 220.0 mm x 43.6 mm
