Identifie
r
Description
B
l 6: 10GE downlink ports
l 5: GE downlink ports
l 3: Layer 3 switch with 100M downlink ports
l 2: Layer 2 switch with 100M downlink ports
C 7: Enterprise series switch
D Product sub-series (such as 00 or 10)
E S: resale model
F Maximum number of ports
NOTE
On an S5710-EI switch (such as S5710-28C-EI), this field indicates the number of fixed
ports on the switch.
G Uplink port type:
l C: The product supports extended cards and its uplink ports are provided
by an extended card or are fixed 10GE ports.
l PC: The product supports extended cards and its uplink ports are provided
by an extended card or are fixed GE ports.
l X: The product has fixed 10GE uplink ports.
l TP: The uplink ports of the product include combo ports consisting of
electrical and optical ports.
l P: The uplink ports of the product are fixed GE optical ports.
NOTE
If the product name does not contain this field, the switch has no uplink port.
H
l PWR: The product supports Power over Ethernet (PoE).
l PWH: The product supports PoE++.
NOTE
If the product name does not contain this field, the switch does not support the PoE
function.
I Device type
l LI: lightweight version
l SI: standard version
l EI: enhanced version
l HI: high-level version, which supports high-performance operation,
administration, and maintenance (OAM) and built-in real-time clock (RTC)
J Downlink port type:
l 24S: 24 downlink SFP optical ports
l 48CS: 48 downlink compact SFP (CSFP) optical ports
NOTE
If the product name does not contain this field, all downlink ports of the switch are
electrical ports.
S5700 Series Ethernet Switches
Hardware Description
3 Chassis
Issue 24 (2016-08-12) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
72
