– Modify the ONU profile according to the actual capability of the ONU and save the
modification. Then, the ONU automatically recovers the configuration successfully.
13.3.6.6 Configuring Management and Service Channel on OLT_B and ONU
After the management service ports is added, you can log in to the ONUs on the OLT and
configure the ONUs. After the GPON service port is added, E1/T1 traffic stream are able to
transmitted upstream to OLT_B.
Prerequisites
Required hardware for OLT_B (cascading) is ready.
l Control board: SCUN+CKMC/CKMD
l GPON service board: GPBD
l Upstream board:
– GE port: GICK
– 10GE port: X2CS
Data Plan
Item Data
Management VLAN and
management IP address for OLT
Management VLAN ID: 8
Management VLAN type: smart
In-band management IP address: 192.168.50.1/24
Service VLAN 300
Management VLAN and
management IP address for ONU
Management VLAN ID: 8
Management VLAN type: smart
In-band management IP address: 192.168.50.2/24
Procedure
Step 1 Configure the in-band management VLAN and IP address for the OLT.
Set the in-band management VLAN to 8, VLAN priority to 6, and IP address to 192.168.50.1/24.
huawei(config)#vlan 8 smart
huawei(config)#port vlan 8 0/19 0
huawei(config)#vlan priority 8 6
huawei(config)#interface vlanif 8
huawei(config-if-vlanif8)#ip address 192.168.50.1 24
huawei(config-if-vlanif8)#quit
Step 2 Configure the in-band management VLAN and IP address for the ONU.
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont ipconfig 1 1 static ip-address 192.168.50.2 mask
255.255.255.0 gateway
192.168.50.1 vlan 8
huawei(config-if-gpon-0/3)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1352
