huawei(config)#vlan 100-101 smart
huawei(config)#vlan attrib 100 stacking
huawei(config)#vlan attrib 101 common
huawei(config)#port vlan 100-101 0/0 0
4. Create a profile for automatic service provisioning by the CNU.
Configure the HSI service profile ID to 1, service VLAN ID to 100, CNU port ID to 1, and
traffic profile to 3.
huawei(config)#cnu auto-service-profile add 1 vlan 100 eth 1 inbound traffic-
table index 3 outbound traffic-table index 3
Configure the interactive TV service profile ID to 1, service VLAN ID to 100, CNU port
ID to 1, and traffic profile to 3.
huawei(config)#cnu auto-service-profile add 1 vlan 101 eth 2 inbound traffic-
table index 4 outbound traffic-table index 4
Step 3 Configure the ONU to provide services through manual operations.
Users must manually configure services after the CNU goes online.
NOTE
Because the management VLAN and the management IP address have been configured, you can remote log in
to the ONU from the OLT to perform the configuration.
1. Log in to the ONU to perform the configuration.
On the OLT, you can remote log in to the ONU to perform the configuration. The user
name is root (default) and the password is mduadmin (default).
2. Optional: Configure a line profile for the EoC head end module.
A line profile is generally not required for the EoC head end module because the default
line profile 1 is automatically bound to the head end module port. For details about how to
customize a line profile, see Configuration Guide of the ONU.
The default profile is used in this example.
3. Optional: Configure a CNU line profile.
A CNU line profile is generally not required because the default line profile 1 is
automatically bound to the CNU. For details about how to customize a line profile, see
Configuration Guide of the ONU.
The default profile is used in this example.
4. Add a CNU to an ONU.
Assume that a CNU ID is 0, the CNU SN is hwhw-12341234, the bound line profile is 1,
the description added to the CNU is huaweicnu, and the CNU alarm reporting function is
disabled by default. To connect this CNU to EoC head end module port 0/1/0, you can use
two methods: add a CNU offline and confirm an automatically discovered CNU.
l Add an CNU offline.
If the CNU SN is known, run the cnu add command to add the CNU offline.
huawei(config)#interface eoc 0/1
huawei(config-if-eoc-0/1)#cnu add 0 0 sn-auth hwhw-12341234 lineprofile-id
1
desc huaweicnu
huawei(config-if-eoc-0/1)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
18 OptiCable EoC Bandwidth Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1867
