a descending order for the VoIP service, IPTV service, and Internet access service. In
this example, set the traffic profile index to 7 and the priority of the Internet access
service to 1.
huawei(config)#traffic table ip index 7 cir 10240 priority 1 priority-
policy
local-Setting
3. Configure a service port.
Add a service port to the VLAN and use traffic profile 7. The user-side VLAN ID is
2.
huawei(config)#service-port vlan 100 eth 0/5/2 multi-service user-vlan 2
rx-cttr 7 tx-cttr 7
huawei(config)#service-port vlan 100 eth 0/5/3 multi-service user-vlan 2
rx-cttr
7 tx-cttr 7
4. Configure queue scheduling.
Use the 3PQ+5WRR queue scheduling. Queues 0-4 adopt the WRR mode, with the
weights of 10, 10, 20, 20, and 40 respectively; queues 5-7 adopt the PQ mode.
NOTE
Queue scheduling is a global configuration. You need to configure queue scheduling only once on
the OLT, and then the configuration takes effect globally. In the subsequent phases, you need not
configure queue scheduling repeatedly when configuring other services.
huawei(config)#queue-scheduler wrr 10 10 20 20 40 0 0 0
Configure the mapping between queues and 802.1p priorities. Priorities 0-7 map
queues 0-7 respectively.
huawei(config)#cos-queue-map cos0 0 cos1 1 cos2 2 cos3 3 cos4 4 cos5 5 cos6
6
cos7 7
NOTE
For the service board that supports only four queues, the mapping between 802.1p priorities and
queue IDs is as follows: priorities 0 and 1 map queue 1; priorities 2 and 3 map queue 2; priorities 4
and 5 map queue 3; priorities 6 and 7 map queue 4.
5. Save the data.
huawei(config)#save
l Configure the VoIP service on the OLT.
1. Create a VLAN and add an upstream port to the VLAN.
The VLAN ID is 200, and the VLAN is a smart VLAN. The upstream port is0/19/0.
huawei(config)#vlan 200 smart
huawei(config)#port vlan 200 0/19 0
2. Configure a traffic profile.
The traffic profile index is 8, and the 802.1p priority of the VoIP service is 6.
huawei(config)#traffic table ip index 8 cir 10240 priority 6 priority-
policy
local-Setting
3. Configure a service port.
Add a service port to the VLAN and use traffic profile 8. The user-side VLAN ID is
3.
huawei(config)#service-port vlan 200 eth 0/5/2 multi-service user-vlan 3
rx-cttr 8 tx-cttr 8
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
719
