Checking the Installation
No. Description Method
1 Do not place any materials on the chassis. Observe
2 All the cables are bound with proper tightness. The space between the cable ties is even, and the
remaining parts of the cable ties are cut off neatly. All cable ties face the same direction, keeping
the overall appearance nice.
Observe
3 The cross sectional area of the power cable and ground cable complies with the engineering design,
and satisfy the requirements of equipment running.
Observe
4 The power cable and ground cable adopt a whole segment of copper core. The cable has no
connection in the middle or scratch on the skin.
Observe
5 The power cable and ground cable must be routed horizontally and vertically without crossover.
Proper margins must be reserved at the turning.
Observe
6 The power cable and ground cable must be connected correctly and reliably. Observe
7 The identifiers on the power cable and ground cable must be correct, legible, and neat. Observe
8 The power cable, ground cable, and signal cables must be routed separately. Observe
9 Signal cables must be long enough, and must not be damaged or broken, without joint in the cable. Observe
10 The connectors of the signal cables must be neat and intact. The connectors must be connected
correctly and firmly. The tips must be connected securely.
Observe
11 Labels at both ends of the signal cables must be marked correctly, clearly and neatly. Observe
12 If the fibers must be routed outside the cabinet, protection measures must be taken, such as using
corrugated pipes or guide troughs.
Observe
13 Place the optical fiber pairs in order and bind them carefully with optical binders. No sharp edge
is allowed.
Observe
14
