Huawei SmartAX MA5608T Quick Installation Guide

Contents
1 Precautions...............................................................................................................................................3
2 Check Tools and Meters .......................................................................................................................4
3 Outline and Structure.............................................................................................................................5
4 Installing the Chassis.............................................................................................................................6
4.1 Installation in a Cabinet or a Rack.................................................................................................................................6
4.2 Installation in the Network Cabinet of the Customer ...................................................................................................7
4.3 Guide for Grounding the Network Cabinet of the Customer ........................................................................................8
5 Routing Cables........................................................................................................................................9
5.1 Routing the PGND Cable and the External Power Cable..............................................................................................9
5.2 Routing Subscriber Cables ..........................................................................................................................................10
5.3 Routing Trunk Cables..................................................................................................................................................11
5.4 Routing Network Cables..............................................................................................................................................12
5.5 Routing Optical Fibers.................................................................................................................................................13
6 Checking the Installation....................................................................................................................14
7 Powering On the System.....................................................................................................................15
2
Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved.

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
