Installation Requirements
3
Device Installation
Dimensions Space
Wall-Mounted Installation
• Install the SmartLogger and SmartModule on a flat and secure interior wall.
• When wall-mounting the SmartLogger and SmartModule, ensure that the cable connection area
faces downward for ease of cable connection and maintenance.
• You are advised to use the delivered tapping screws and expansion tubes.
1. Connect the SmartLogger to the SmartModule using a connecting plate.
If the SmartLogger
and SmartModule
have been
combined before
delivery, skip this
step.
To Next Page
