4.2 Tools

Category Tool

Installation tools

Hammer drill

Drill bit (Ф14

mm and Ф16

mm)

Insulated torque

socket wrench

(including an

extension bar ≥

50 mm)

Phillips insulated

torque

screwdriver

Flat-head

insulated torque

screwdriver

Wire strippers Diagonal pliers Rubber mallet

Utility knife

Cable cutter

Crimping tool

Model: H4TC0003

Manufacturer:

AMPHENOL

(For Amphenol

Helios H4

connectors only)

Open-end

wrench

Model:

H4TW0001

Manufacturer:

AMPHENOL

(For Amphenol

Helios H4

connectors only)

SUN2000-(100KTL, 110KTL, 115KTL)-M2

User Manual 4 Installation
