No. Parameter Description
6 Grid reconnection
voltage upper limit (V)
The standards of certain countries and regions require that after
the inverter shuts down for protection due to a fault, if the
power grid voltage is higher than Grid reconnection voltage
upper limit, the inverter is not allowed to reconnect to the grid.
7 Grid reconnection
voltage lower limit (V)
The standards of certain countries and regions require that after
the inverter shuts down for protection due to a fault, if the
power grid voltage is lower than Grid reconnection voltage
lower limit, the inverter is not allowed to reconnect to the grid.
8 Grid reconnection
frequency upper limit
(Hz)
The standards of certain countries and regions require that after
the inverter shuts down for protection due to a fault, if the
power grid frequency is higher than Grid reconnection
frequency upper limit, the inverter is not allowed to reconnect
to the grid.
9 Grid reconnection
frequency lower limit
(Hz)
The standards of certain countries and regions require that after
the inverter shuts down for protection due to a fault, if the
power grid frequency is lower than Grid reconnection
frequency lower limit, the inverter is not allowed to reconnect
to the grid.
7.1.4.2 Setting Protection Parameters
Choose Settings > Protection parameters to set protection parameters.
No.
Parameter Description
1 Unbalance voltage
protection threshold
(%)
Species the inverter protection threshold when the power grid
voltage is unbalanced.
2 Insulation resistance
protection threshold
(MΩ)
To ensure device safety, the inverter detects the insulation
resistance of the input side with respect to ground when it
starts a self-check. If the detected value is less than the preset
value, the inverter does not connect to the grid.
4 Phase angle oset
protection
The standards of certain countries and regions require that the
inverter needs to be protected when the phase angle oset of
the power grid three phases exceeds a certain value.
5 Voltage threshold for
10-minute overvoltage
protection (V)
Species the 10-minute overvoltage protection threshold.
6 Duration threshold for
10-minute overvoltage
protection (ms)
Species the 10-minute overvoltage protection duration.
SUN2000-(100KTL, 110KTL, 115KTL)-M2
User Manual 7 Man-Machine Interactions
Issue 07 (2023-04-30) Copyright © Huawei Technologies Co., Ltd. 86
