Huawei SUN2000-12KTL-M2 User Manual

Symbol Description
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.
Supplements the important information in the main text.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue
contains all updates made in previous issues.
Issue 11 (2023-02-07)
● Updated 2.1 Product Introduction.
● Updated 5.2 Preparing for Installation.
● Updated 5.7.2 Connecting the RS485 Communications Cable (Smart Power
Sensor).
● Updated 5.7.5 Connecting the NS Protection Signal Cable.
● Updated 7.1.3 Creating a PV Plant and a User.
● Updated 7.1.4 (Optional) Setting the Physical Layout of the Smart PV
Optimizers.
● Updated 7.2 Parameters Settings.
Issue 10 (2022-10-10)
● Updated 5.2 Preparing for Installation.
● Updated 5.4 Connecting the AC Output Power Cable.
Issue 09 (2022-06-30)
● Updated 5.2 Preparing for Installation.
● Updated 5.7.2 Connecting the RS485 Communications Cable (Smart Power
Sensor).
● Updated 10.1 SUN2000 Technical
Specications.
● Updated A Grid Codes.
Issue 08 (2022-03-04)
● Updated 5.7.2 Connecting the RS485 Communications Cable (Smart Power
Sensor).
SUN2000-(8KTL-20KTL)-M2
User Manual About This Document
Issue 11 (2023-02-07) Copyright © Huawei Technologies Co., Ltd. iii

Huawei SUN2000-12KTL-M2 Specifications

General

Model	SUN2000-12KTL-M2
Max. Efficiency	98.6%
Max. Input Voltage	1100 V
Start Voltage	200 V
Rated Output Power	12000 W
Output Frequency	50 Hz / 60 Hz
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Rating	IP65
Max. DC Input Power	18, 000 W
Max. AC Power	13200 W
Rated Output Voltage	400 V
AC Voltage Range	320 V - 480 V
Max. DC Power	18, 000 W
