Huawei SUN2000-12KTL-M2 User Manual

6 Commissioning
D ANGER
● Wear insulated gloves and use insulated tools to prevent electric shocks or
short circuits.
6.1 Check Before Power-On
Table 6-1 Installation checklist
No.
Check Item Acceptance Criteria
1 SUN2000 installation The SUN2000 is installed correctly, securely, and
reliably.
2 Smart Dongle The Smart Dongle is installed correctly and
securely.
3 Cable layout Cables are routed properly as required by the
customer.
4 Cable tie Cable ties are secured evenly and no burr exists.
5 Grounding The ground cable is connected correctly,
securely, and reliably.
6 Turn o the switches The DC SWITCH and all the switches connected
to the SUN2000 are set to OFF.
7 Cable connections The AC output power cable, DC input power
cable, and signal cable are connected correctly,
securely, and reliably.
8 Unused terminals and ports Unused terminals and ports are locked by
watertight caps.
SUN2000-(8KTL-20KTL)-M2
User Manual 6 Commissioning
Issue 11 (2023-02-07) Copyright © Huawei Technologies Co., Ltd. 70

Huawei SUN2000-12KTL-M2 Specifications

General

Model	SUN2000-12KTL-M2
Max. Efficiency	98.6%
Max. Input Voltage	1100 V
Start Voltage	200 V
Rated Output Power	12000 W
Output Frequency	50 Hz / 60 Hz
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Rating	IP65
Max. DC Input Power	18, 000 W
Max. AC Power	13200 W
Rated Output Voltage	400 V
AC Voltage Range	320 V - 480 V
Max. DC Power	18, 000 W
