Huawei SUN2000-12KTL-M5 Series User Manual

Item SUN2000-
12KTL-M5
SUN2000-
15KTL-M5
SUN2000-
17KTL-M5
SUN2000-
20KTL-M5
SUN2000-
25KTL-M5
Number of
MPPTs
2
Note a: The maximum input voltage is the maximum DC input voltage that the
inverter can withstand. If the input voltage exceeds this value, the inverter may
be damaged.
Output
Item SUN2000-
12KTL-M5
SUN2000-
15KTL-M5
SUN2000-
17KTL-M5
SUN2000-
20KTL-M5
SUN2000-
25KTL-M5
Rated
output
power
12000 W 15000 W 17000 W 20000 W 25000 W
Maximum
apparent
power
13200 VA 16500 VA 18700 VA 22000 VA 27500 VA
Maximum
active
power
(cosφ = 1)
13200 W 16500 W 18700 W 22000 W 27500 W
Rated
output
voltage
220 V/380 V, 3W/N+PE
230 V/400 V, 3W/N+PE
239.6 V/415 V, 3W/N+PE
Maximum
output
voltage at
long-term
operation
See standards about the local power grid.
Rated
output
current
18.2 A/380
V
17.3 A/400
V
16.7 A/415
V
22.8 A/380
V
21.7 A/400
V
20.9 A/415
V
25.8 A/380
V
24.5 A/400
V
23.7 A/415
V
30.4 A/380
V
28.9 A/400
V
27.8 A/415
V
38.0 A/380
V
36.1 A/400
V
34.8 A/415
V
Maximum
output
current
20.2 A/380
V
19.1 A/400
V
18.5 A/415
V
25.2 A/380
V
23.9 A/400
V
23.1 A/415
V
28.6 A/380
V
27.1 A/400
V
26.1 A/415
V
33.6 A/380
V
31.9 A/400
V
30.8 A/415
V
42.0 A/380
V
39.9 A/400
V
38.5 A/415
V
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 10 (2024-05-14) Copyright © Huawei Digital Power Technologies Co., Ltd. 82
