Replacing SUN2000-(15KTL-50KTL) Series with
SUN2000-(15KTL-50KTL)-M3 Series
User Manual
Copyright © Huawei Technologies Co., Ltd.
Figure 6-8 Connecting DC power cables
If the original DC input power cables are not long enough, use the DC input extension cables delivered
with the package.
Figure 6-9 Connecting the DC input extension cable
----End
6.2.4 Connecting the Signal Cables
COM Port Pin Definitions
Ensure that the protection layers of the cables are inside the connector, that excess core wires
are cut off from the protection layer, that the exposed core wires are totally inserted into the
cable hole, and that the cable is connected securely.
