Single-Core Cable
(three rings)
(two rings)
(one ring)
(four rings)
The 32–36 mm cable is supported only
by some models. Refer to the
corresponding label to get the
supported size.
Bending Radius
Multi
-Core Cable
Single
-Core Cable
Unarmored
Armored
Unarmored
Armored
R
≥ 15D
R
≥ 12D
R
≥ 20D
R
≥ 15D
R indicates the bending radius, and D indicates the
outer diameter of the cable.
The AC power cable must be
routed vertically into the
maintenance compartment.
(five rings)
