Huawei SUN2000-20KTL-M2

Other manuals for Huawei SUN2000-20KTL-M2

Questions and Answers:

J
Jose MorrisAug 31, 2025
What does Unbalanced Grid Voltage mean on my Huawei Inverter?
- K
  kgreeneSep 1, 2025
  If your Huawei Inverter is showing an 'Unbalanced Grid Voltage' error, it means that the difference between grid phase voltages exceeds the upper threshold. Here's what to do: 1. If the alarm occurs occasionally, the power grid may be temporarily abnormal. The SUN2000 automatically recovers after detecting that the power grid becomes normal. 2. If the alarm occurs frequently, check whether the grid voltage is within the acceptable range. If no, contact the local power operator. 3. If the fault persists for a long time, check the connection between the AC switch and the output power cable.
K
Karen AndersonSep 12, 2025
What causes String Reverse Connection on Huawei SUN2000-20KTL-M2 Inverter?
- P
  Patrick JacobsSep 12, 2025
  If your Huawei Inverter reports a 'String Reverse Connection' error, it means the PV string polarity is reversed. To correct this, check if the PV string is reversely connected to the SUN2000. If it is, wait until the PV string current decreases below 0.5 A, set the DC SWITCH to OFF, and then adjust the PV string polarity.
M
Melissa WillisAug 29, 2025
What causes String Current Backfeed on a Huawei SUN2000-20KTL-M2 Inverter and how to resolve it?
- J
  Julia GonzalezAug 29, 2025
  If your Huawei Inverter reports 'String Current Backfeed,' it means that too few PV modules are connected in series, causing the end voltage to be lower than other PV strings. To resolve this: 1. Check if the number of PV modules connected in series is less than that of other PV strings. If so, wait until the PV string current drops below 0.5 A, set the DC SWITCH to OFF, and adjust the number of PV modules. 2. Check if the PV string is shaded. 3. Check if the open-circuit voltage of the PV string is normal.
T
Tracy PearsonSep 12, 2025
How do I fix Phase Wire Short-Circuited to PE on Huawei SUN2000-20KTL-M2?
- P
  Patricia SmithSep 13, 2025
  If your Huawei Inverter indicates 'Phase Wire Short-Circuited to PE', it means the impedance of the output phase wire to PE is low, or the output phase wire is short-circuited to PE. To resolve this, check the impedance of the output phase wire to PE, find the location with lower impedance, and fix the fault.
D
Dr. Leslie RileySep 12, 2025
What to do for String Current Backfeed on Huawei SUN2000-20KTL-M2?
- V
  Victor MendozaSep 12, 2025
  If your Huawei Inverter is showing a 'String Current Backfeed' error, it means that the number of PV modules connected in series to this PV string is insufficient, causing the end voltage to be lower than that of other strings. To resolve this: 1. Check if the number of PV modules connected in series to this PV string is less than the number of PV modules connected in series to the other PV strings connected in parallel with this PV string. If so, wait until the PV string current decreases below 0.5 A, set DC SWITCH to OFF, and adjust the number of PV modules in the PV string. 2. Check if the PV string is shaded. 3. Check if the open-circuit voltage of the PV string is normal.
J
Jeffery MilesSep 16, 2025
What does Abnormal Residual Current mean on Huawei Inverter?
- S
  Steven RhodesSep 16, 2025
  If your Huawei Inverter is showing an 'Abnormal Residual Current' error, it indicates that the input-to-ground insulation impedance has decreased during the inverter operation. To address this: 1. If the alarm occurs accidentally, the external power cable may be temporarily abnormal. The inverter will automatically recover once the fault is rectified. 2. If the alarm occurs frequently or persists, check that the impedance between the PV string and ground is not below the lower threshold.
H
harmontinaSep 23, 2025
How to troubleshoot Abnormal PV Module Configuration on Huawei SUN2000-20KTL-M2?
- J
  Jose NavarroSep 23, 2025
  If your Huawei Inverter reports 'Abnormal PV Module Configuration,' it means the PV module configuration doesn't meet requirements, or the PV module output is reversely connected or short-circuited. Check whether the total number of PV modules, the number of PV modules in a string, and the number of PV strings meet requirements, and verify that the PV module output isn't reversely connected.
M
mollydurhamAug 27, 2025
How to fix String Reversed error on Huawei SUN2000-20KTL-M2?
- T
  theresa62Aug 27, 2025
  If your Huawei Inverter displays a 'String Reversed' error, it means the PV string is reversely connected. To fix this, wait until night when solar irradiance declines and the PV string current drops below 0.5 A. Then, set the DC SWITCH to the OFF position and correct the string polarity.
K
Kaitlyn HannaAug 26, 2025
What to do if my Huawei Inverter shows a Grid Failure?
- F
  frank85Aug 26, 2025
  If your Huawei Inverter reports a grid failure, it means that the power grid has experienced an outage, the AC circuit is disconnected, or the AC switch is off. To resolve this, first, check the AC voltage. Second, check whether the AC circuit is disconnected or the AC switch is off.
D
dorisvasquezAug 25, 2025
How to fix Low Insulation Resistance on Huawei Inverter?
- C
  christinaleonAug 26, 2025
  If your Huawei Inverter displays a 'Low Insulation Resistance' error, it could be due to the PV array being short-circuited to ground or the power cable not being well insulated, especially in a moist environment. Here's what you should do: * Check the impedance between the PV array output and PE, and eliminate any short circuits or points of poor insulation. * Ensure the PE cable for the inverter is correctly connected. * If you're certain the impedance is less than the preset protection threshold in cloudy or rainy conditions, you can log in to the mobile app, SmartLogger, or NMS to reset the insulation impedance protection threshold.

Huawei SUN2000-20KTL-M2 Specifications

General

Model	SUN2000-20KTL-M2
Type	String Inverter
Max. efficiency	98.6%
European efficiency	98.3%
Max. input voltage	1100 V
Max. input current per MPPT	26 A
Number of MPPTs	2
Rated output power	20, 000 W
Start Voltage	200 V
MPPT Voltage Range	200 V - 1000 V
Max. AC Power	22, 000 VA
Output Frequency	50 Hz / 60 Hz
Dimensions (W x H x D)	525 x 470 x 262 mm
Weight	25 kg
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Rated AC Voltage	230 V / 400 V
Max. Input Power	30, 000 W
Max. Output Power	22, 000 W
Rated Output Voltage	230 V / 400 V

Summary

About This Document

Purpose

Describes the SUN2000 inverter, its installation, electrical connections, commissioning, maintenance, and troubleshooting.

Intended Audience

Lists the target readers for this document, including installers and users.

Symbol Conventions

Explains the meaning of symbols used throughout the document for safety and information.

Safety Information

1.1 Personal Safety

Safety guidelines for personal protection during operations, including precautions against electric shock.

1.2 Electrical Safety

Safety guidelines related to electrical hazards, grounding, and cable connections.

1.3 Environment Requirements

Guidelines for selecting and maintaining a safe operating environment for the equipment.

1.4 Mechanical Safety

Safety precautions for physical handling, mounting, and moving of the equipment.

Moving Heavy Objects

Procedures and precautions for safely moving heavy equipment to prevent injury.

Using Ladders

Guidelines for safe use of ladders during work at heights.

Hoisting and Drilling Safety

Safety procedures for hoisting operations and drilling holes.

Overview

2.1 Product Introduction

Introduces the SUN2000 inverter and its function in converting DC power to AC power.

Network Application

Describes typical grid-tied system configurations and components.

2.2 Appearance

Details the physical components, ports, and indicators of the SUN2000 inverter.

2.3 Label Description

Explains various labels, symbols, and warnings found on the equipment.

2.3.1 Enclosure Labels

Describes symbols and their meanings found on the equipment enclosure.

2.3.2 Product Nameplate

Details the information provided on the product nameplate.

2.4 Working Principles

Explains the operational principles and conceptual diagram of the SUN2000.

2.4.1 Circuit Diagram

Illustrates the conceptual circuit diagram of the SUN2000.

2.4.2 Working Modes

Describes the different operating modes of the SUN2000: Standby, Operating, and Shutdown.

Storage

Installation

4.1 Checking Before Installation

Procedures for checking outer packing materials and inverter model before installation.

4.2 Tools

Lists the tools required for installation, categorized by type.

4.3 Determining the Installation Position

Guidelines for selecting the optimal installation location for the inverter.

4.3.1 Environment Requirements

Specifies environmental conditions for safe and optimal installation.

4.3.2 Space Requirements

Details the necessary space around the unit for installation and heat dissipation.

4.4 Moving an Inverter

Provides instructions for safely moving the inverter during installation.

4.5 Installing the Mounting Bracket

Instructions for installing the mounting bracket for the inverter.

4.5.1 Wall-mounted Installation

Step-by-step guide for wall-mounting the inverter bracket.

4.5.2 Support-mounted Installation

Step-by-step guide for installing the mounting bracket on supports.

Electrical Connections

5.1 Precautions

General safety precautions before making electrical connections.

5.2 Preparing for Installation

Steps to prepare for electrical connections, including cable selection.

5.3 Connecting the PE cable

Instructions for properly connecting the protective earth (PE) cable.

5.4 Connecting the AC Output Power Cable

Detailed steps for connecting the AC output power cable.

5.5 Connecting the DC input power cable
