9
Main menu
screen
Quick
settings
The preset passwords for Common User, Advanced User, and Special User are 00000a.
Use the preset password upon initial login. To ensure account security, change the password
immediately after login.
The screen snapshots in this document correspond to app 2.2.00.035 (Android).
Set the correct grid code based on the application region and scenario of the SUN2000.

Other manuals for Huawei SUN2000-20KTL

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei SUN2000-20KTL and is the answer not in the manual?

Huawei SUN2000-20KTL Specifications

General IconGeneral
Max. efficiency98.6%
Rated AC output power20, 000 W
Max. apparent power22, 000 VA
No. of MPP trackers2
Max. input voltage1100 V
Protection degreeIP65
Max. DC Power30, 000 W
Start Voltage200 V
Nominal DC Voltage600 V
Max. Input Current per MPPT26 A
Nominal AC Grid Frequency50 Hz / 60 Hz
Adjustable Power Factor Range0.8 leading to 0.8 lagging
Total Harmonic Distortion (THD)<3%
DC Reverse-Polarity ProtectionYes
AC Overcurrent ProtectionYes
AC Short-Circuit ProtectionYes
DC Insulation Resistance DetectionYes
Residual Current MonitoringYes
AC Overvoltage ProtectionYes
DC SwitchYes
Cooling MethodNatural Convection
AC output voltage220 V / 380 V, 230 V / 400 V
MPPT operating voltage range200 V - 1000 V
Operating temperature range-25°C to +60°C
Relative Humidity0% - 100%
Operating AltitudeUp to 4000 m
Surge ProtectionType II DC & AC
