Huawei SUN2000-5KTL-L1 Quick Guide

6
• If your Smart Dongle is configured with a SIM card, you do not need to install the SIM card. The
configured SIM card can be used only on the Smart Dongle. The SIM card is a China Mobile
card. Before installation, check whether the site is effectively covered by China Mobile signals.
If not, prepare a SIM card of other carriers.
• If your Smart Dongle is not equipped with a SIM card, prepare a standard SIM card (size: 25
mm x 15 mm) with the capacity greater than or equal to 64 KB.
(Optional) 4G Smart Dongle (4G Communication)
• For details about how to operate the WLAN-FE Smart Dongle SDongleA-05, see SDongleA-05
Quick Guide (WLAN-FE).
• For details about how to operate the 4G Smart Dongle SDongleA-03, see SDongleA-03 Quick
Guide (4G).
• The quick guide is delivered with the Smart Dongle. You can download them by scanning the
QR code below.
WLAN-FE 4G
• Install the SIM card in the arrow direction.
• When reinstalling the cover of the Smart Dongle, ensure that the buckle springs back in place
(you can hear a click).

Huawei SUN2000-5KTL-L1 Specifications

General

Model	SUN2000-5KTL-L1
Max. Efficiency	98.4%
Rated AC Output Power	5000 W
Operating Temperature Range	-25°C to +60°C
Topology	Transformerless
Max. apparent AC power	5500 VA
Max. input voltage	600 V
Number of MPPT trackers	2
Max. short-circuit current per MPPT	15 A
Protection degree	IP65
Max. Input Power	7500 W
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Nominal AC voltage	230 V
AC voltage range	180 V - 280 V
Rated Output Voltage	230 V
