3
2
Installation Requirements
Recommended: 600 mm ≤ Bottom space ≤ 730 mm
Angle Space
Dimensions
The DC switch is ON and can automatically turn off for protection.
The DC switch is ON but cannot automatically turn off for protection.
When the DC switch automatically turns off for protection, the RESET button
will be released.
•
When the RESET button is not pressed, the DC switch can only be turned to the
unloaded position , and cannot be set to the ON position.
If inverters are installed in a place with abundant vegetation, in addition to routine weeding,
harden the ground underneath the inverters using cement or gravel (recommended area: 3 m x
2.5 m).
