U8800 Maintenance Manual Basic Version V1.1 Internal
2011-03-21
Huawei confidential. No spreading without permission. Page 35 of 61
U301
VREG_MSMA-test
C402
2.85V
Figure9-2
U301
U301
VREG_MSMP-tes
t
C430
1.3V
U301
VREG_MSME-test
C433
2.6V
U301
VREG_S2(RFRX)-
test L403
1.3V
U301
VREG_S4(RFTX)-
test L405
2.2V
X401 Pin1 19.2MHz
U301
VREG_WLAN-tes
t
C434
3.0V
U1701
X401
