3 Explosive View of the Whole Unit
This exploded view is only applied to show phone frame. It is not regarded as a reference for applying
spare parts.
NO. Description Quantity
1 Main_lens 1
2 Touch _lens 1
3 Front_cover_ASM 1
4 LCD_ASM 1
5 Metal_frame 1
6 MIC_Rubber 1
7 Sub_PCB 1
8 Volume_Key_DOME 1
9 Power_Key_DOME 1
10 Main_PCB 1
11 Mpcb_Foam 1
1
2416
5 7 9 11 13 15 17 19 21
14
23
25
3
6 8 10 18 20 224 2 12
