Huawei UPS2000-G-10KRTL Quick Guide

1
UPS Model Represented By Weight
Dimensions (H x W x D)
UPS2000
-G-6KRTS/UPS2000-G-6KRTL
6
kVA
14
kg
86 mm x 430 mm x 615 mm
UPS2000
-G-10KRTS/UPS2000-G-
10KRTL
10
kVA
16
kg
86 mm x 430 mm x 615 mm
Overview
6 kVA/10 kVA Front View
No.
Name
Description
1
LCD
-
2
Mains indicator
•
On: Normal mode
•
Off: Mode other than
normal mode
3
Battery indicator
•
On: Battery mode
•
Off: Mode other than
battery mode
•
Blinking: The battery
reserve is less than 25%.
4
Bypass indicator
•
On: Bypass mode
•
Off: Mode other than
bypass mode
5
Fault
indicator/INFO
button
•
Red on: UPS fault
•
Blinking red: UPS alarm
•
Green: The UPS is running
properly.
6
Confirm/Start
button
Enter/Startup/Mute/Battery
self
-check
7
Page Down key
-
8
Page Up key
-
9
ESC/Shutdown
button
Returns to an upper
-level
menu, or shuts down the UPS.
The UPS is working in ECO mode
only if the mains indicator and
bypass indicator are both on.
(1) Battery terminal
cover
(2) Input circuit breaker
(3) Fuse port
(4) Maintenance bypass
port (MBS)
(5) EPO port
(6) USB port
(7) Battery temperature
sensor port
(8) Cover for optional
card slot
(9) CAN
communications port
(10) Parallel port
(11) Output sockets
(12) AC input and
output terminal
cover
10 kVA Rear View
6 kVA Rear View
ESC
UG06009966
1
2
89 7 6
3 4 5
BATT.240VDC
PE
PE N PE NL sL pL
OFF ONACINPUT
ACI NPUT ACOUTPUT
+
12 11 10 9 8
7654321
BATT.240VDC
PE
PE PEN NL3 L1L2 sL pL
OFF ONAC INPUT
ACINPUT
+
ACOUTPUT
10 9 8
765421
UG06009965
