Environment Monitoring Screen
Figure 4-16 Environment Monitoring screen
Table 4-12 Environment Monitoring
Item Description
Ambient temp. Temperature detected by the ambient temperature
and humidity sensor (used together with an SNMP
card; if the sensor is not connected, N/A is
displayed.)
Ambient humidity Humidity detected by the ambient temperature
and humidity sensor (used together with an SNMP
card; if the sensor is not connected, N/A is
displayed.)
Internal temp. Temperature of the air near the air intake vent of
the UPS.
Runtime Screen
Figure 4-17 Runtime screen
Table 4-13 Runtime
Item
Description
Inv. runtime Total time during which the UPS runs in inverter
mode.
BPS runtime Total time during which the UPS runs in bypass
mode
UPS2000-G- (6 kVA-20 kVA)
User Manual 4 Control Panel
Issue 18 (2021-07-16) Copyright © Huawei Technologies Co., Ltd. 54
