UPS2000-G-(1 kVA-3 kVA)
User Manual
2 Overview
Issue 15 (2019-12-19)
Copyright © Huawei Technologies Co., Ltd.
18
Figure 2-7 Rear view of UPS2000-G-3KRTS
(1) Mains input socket (C20)
(2) Input circuit breaker
(3) USB port
a
(security protection mechanism supported)
(4) RS232 port
(5) Optional card slot
(6) Output socket (C13)
(7) Output socket (C19)
Figure 2-8 Rear view of UPS2000-G-3KRTL
(1) Mains input socket (C20)
(2) Input circuit breaker
(3) USB port
a
(security protection
mechanism supported)
(4) RS232 port
(5) Optional card slot
(6) Output socket (C13)
(7) Output socket (C19)
(8) External battery connector (only for long
backup time models)
a: The USB port supports the standard Modbus protocol and can be connected to the NMS over a USB
cable.
2.4 Optional Components
Optional
Component
Model
Function
Remarks
Ambient
ENR1DETA MODULE
Measures the UPS
Used together
