Electronic Overspeed Switch EGS 40
10
EGS40_MANUAL-en_R6(2018-11-07)ID74528.docx
3.2.1 Mechanical Data
Description
Data
Vibration resistance
DIN EN 60068-2-6 / IEC 68-2-6 (10 … 2000 Hz)
20 g (=200 m/s²)
Shock resistance
DIN EN 60068-2-27 / IEC 68-2-27 (6 ms)
100 g (ca. 1000 m/s²)
EGS 40
Max. encoder
shaft load
Fa max. (axial) = 100 N
Fr max. (radial) = 120 N
Shaft end
11j6 x 30 mm (standard)
14j6 x 30 mm (optional)
Weight
EGS 40 K
EGS 40 KK
Approx. 3.3 kg
Approx. 3.6 kg
EGSH 40
Weight
EGSH 40 K
EGSH 40 KK
Approx .3,5 kg
Approx. 3,8 kg
3.3 Connected loads and values
3.3.1 Dimensions, connected loads, environment
Specification
Value
Unit
Weight
approx. 3,5
kg
Dimensions
see dimensions sheet page
Supply voltage
12 … 30
V DC
Power consumption
80
mA
Switching voltage see type plate
(Special switching voltage, see type plate)
2 … 30
30 … 230
V DC
V AC/DC
Switching current
max. 300
mA
Device temperature range
-25 … +85
°C
max. shaft stress, shaft 11j6 x 30 and
14j6 x 30 (up to speed 3000 rpm)
axial, 100, radial, 120
on a half shaft length
N
3.3.2 Electrical Outputs
Variant
Switching
Contacts
Error
Outputs
Incremental
Output
Supply
Voltage
Connection
Diagram
See chapter 13.1
EGS(H) 40K (HS)
2
1
12 30 VDC
PN132-400
EGS(H) 40KK (HS)
4
2
12 30 VDC
PN132-400
EGS(H) 40KK
– FG 40
2
1
6/8
12 30 VDC
PN132-420
+ Connection diagram for
FG40 see Operating
manual FG40
EGS(H) 40KK (HS) –
HV
2
1
100 .. 240
V AC
PN132-420 +
PN100-400a
Option S
2
1
PN132-420
