Electronic Overspeed Switch EGS 40
EGS40_MANUAL-en_R6(2018-11-07)ID74528.docx
9
3.2 Type key
EGS(H) 40 K -HS –HV /20P - FG 40-1024G-90G-NG
Electronic Overspeed Switch
EGS
EGSH (hollow shaft design)
Series 40
Connection Method
K: Terminal box
KK: 2 Terminal boxes
Switching Voltage
max. 30 V DC (Standard)
HS: 30 … 230 V AC/DC
Supply Voltage
12 … 30 V DC (Standard)
HV: 100 … 240V AC (in second terminal box)
Inner diameter (hollow shaft version)
20 P: Ø 20 H7 mm with keyway (standard)
16 P: (Optional)
19 P: (Optional)
16 K: (Optional) K: Klemmung/clamp
25 K: (Optional)
Integrated incremental encoder
(in the second terminal box)
see (assembly) instructions FG 40
