Huck 202 - Measuring; Tool

Y
X
17
202 Series Tooling (HK938) Alcoa Fastening Systems
M
M
EASURING
EASURING
T
T
OOL
OOL
S
S
TROKE
TROKE
202, 202B, & 202V
Step 1
Cycle Piston all the way forward and measure X.
Step 2
Cycle and hold piston back and measure Y.
Step 3
Stroke = Y-X
X
Y
202L & 202LV
Step 1
Cycle Piston all the way forward and
measure X.
Step 2
Cycle and hold piston back and
measure Y.
Step 3
Stroke = X-Y
FIG. 12
FIG. 13
