Huck 202 - Parts List

20
202 Series Tooling (HK938) Alcoa Fastening Systems
P
P
ARTS
ARTS
L
L
IST
IST
Item Description Qty 202 202L 202B 202V 202LV
1*
Handle Assembly 1 128178
2 Cable Assembly 1 116404-1
3 Dowel Pin 1 505496
4 Pin 1 500621
5 Trigger 1 124333-1
6 Piston Assembly (incl. items 16,17,&18) 1 123774 125495 123774 123774-1 125495-1
7 Retaining Nut 1 111795
8 Adapter 1 123761
9 Wiper Seal 1 505817
10 Gland Cap 1 122432
11 Back-up Ring 1 501110
12 O-Ring 1 500816
13 Retaining Ring 1 502274-
14 Polyseal 1 505818
15 Front Gland 1 123757
16 Retaining Ring 1 506653
17 Washer 1 506654
18 Polyseal 1 506160
19 Compression Spring 1 506492
20
WARNING Sticker
1 590240-1
21 End Cap 1 125150 124341 123577
22 Spacer / Washer 1 124828
23 Wiper Seal 1 506488
24 Pintail Deflector / Bottle 1 124211 123772
25 Gland Assembly 1 116134-1
26 Gland Housing 1 125139
27 O-ring 1 500786
28 Polyseal 1 506566
29 Spacer 1 123906
30 Retaining Ring 1 506565
31 O-ring 1 500784
32 Back-up Ring 1 501090
33 QUAD Ring 1 501414
34 Bumper 1 116408
35*
Cylinder Assembly 1 123752
36 Piston, Rod 1 111803-1
37 Air Piston 1 123753
38 Retaining Ring 1 506490
39 Gasket 1 126941-1
40 Screw 3 504127
* When replacing Cylinder Assembly (35) Stickers (59, 60, & 61) MUST be ordered and placed in the location shown in Figure 14.
** When replacing Handle Assembly (1), WARNING Sticker (20) MUST be ordered and placed in the location shown in Figure 14.
