Ver. 1.0 – 10/17
Specifications___________________________________________________
Model Number: HC10XA-(xx)
Color (xx): BK=Black; WH=White; SV=Silver
Camera & Lens
• Video CMOS Sensor 1/2.8” CMOS, 2.1 Mega Pixel
• Resolutions 1080p-30/25, 720p-30/25, SVGA, VGA
• Frame Rate Up to 30fps (MJPEG)
• Lens Zoom 10X Optical Zoom f=4.7-47mm F1.6
• Min Lux 0.1 Lux at F1.6
• Horizontal Field of View 7° (Tele) to 57° (Wide)
Built-in Audio
• Mic Array Dual Mics on front of camera base
• Pickup Range 360° up to 16.5 ft (5m)
• Processing Advanced Auto Gain and Noise Control
Pan/Tilt Movement
• Pan Movement ±340°
• Tilt Rotation Up: 90°, Down: 30°
• Presets 64 Presets
Rear Board Connectors
• Video interface USB 2.0
• Control Signal Interface USB 2.0 Virtual Com Port (VISCA, PelcoD)
• Baud Rate 9600, 38400 bps
• Audio Interface USB 2.0 Plug and Play
• Power Supply Interface DC 12V 1.2A
Electrical Index
• Power Supply Adapter 12V DC 2A
• Input Voltage 12V DC (10.5-14V DC)
• Input Power 15W (Max)
Physical
• Material Aluminum, Plastic
• Dimensions 7.1”W x 5.2”H x 3.1”D
(180mm x 132mm x 78mm [140mmH w/ tilt])
• Weight 1.41 lbs (0.64 kg)
• Color Black, White, *Silver (* Special Order
• Operating Temperature 32°F to + 113°F (0°C to +45°C)
• Storage Temperature -14°F to 140°F (-10°C +60°)
• Working Environment Indoor only
Warranty
• Mfg Warranty 2 Years parts and labor
