HuddleCamHD 10XA - Dip Switch Settings

Ver. 1.0 – 10/17
Dip-Switch Settings_________________________________________
Bottom Switch: Used for serial and IR communication settings.
Note: When changing Dip-Switch settings, make all changes with camera powered off.
DIP-1,2:
Virtual COM Port – Baud Rate & Communication Protocol
Baud Rate
Switch State
Communication
Protocol
Switch State
DIP-1
DIP-2
9600bps
OFF (Default)
VISCA
OFF (Default)
38400bps
ON
PELCO-D
ON
DIP-3,4,5:
IR Remote Control – Camera ID
IR Remote Address
Switch State
DIP-3
DIP-4
DIP-5
1 (Default)
OFF (Default)
OFF (Default)
OFF (Default)
1
ON
OFF
OFF
2
OFF
ON
OFF
3
OFF
OFF
ON
OSD Menu_____________________________________________________
Dome__________________________________________________________
• Pan Speed Default Value: 20
o Set speed of Pan motor
▪ Range = 1 – 63
• Tilt Speed Default Value: 20
o Set speed of Tilt Motor
▪ Range = 1 – 63
