10.1 Inputs
INSTRUMENT Input Input 6.3 mm (1/4“) jack
Type unbalanced
Input impedance 1 M Ω
Sensitivity - 50 dB (Clean Channel)
Max. Input Level 0 dB
FX Return Input 6.3 mm (1/4”) jack
Type unbalanced
Input impedance 48 k Ω
Max. sensitivity -10 dB button engaged: - 21 dB, disengaged: - 11 dB
Max. Input Level -10dB button engaged: + 0 dB, disengaged + 10 dB
MIDI IN Port DIN 45 329 (7-pin)
Data reception Program change data, Tap Delay function
Channels 16, Omni mode
Power supply 15V DC max. 200mA, pin 6 = positive, pin 7 = negative
10.2 Outputs
FX Send Output 6.3 mm (1/4“) jack
Type unbalanced
Output impedance 2.2 k Ω
Output Level + 3 dB
Max. output Level -10dB button engaged: - 2 dB, disengaged: + 8 dB
MIDI THRU Port DIN 45 328 (5-pin)
Data handling All data sent to MIDI IN are patched, out unchanged.
Speaker Outputs 6.3 mm (1/4“) jacks 1 x 4 Ω, 2 x 16 Ω / 1 x 8 Ω, 1 x 16 Ω
Speaker 100 TSC Combo 2 x 12“ Eminence Rockdriver 60
50 TSC Combo 1 x 12“ Eminence Rockdriver 60
10.3 General Electrical Data Switchblade 100 TSC Head Switchblade 100 TSC Combo Switchblade 50 TSC Combo
Max. current consumption 440 Watts 440 Watts 290 Watts
Max. power consumption 1,75A @ 240 Volts 1,75A @ 240 Volts 0,97A @ 240 Volts
1,89A @ 220-230 Volts 1,89A @ 220-230 Volts 1,07A @ 220-230 Volts
3,50A @ 117-120 Volts 3,50A @ 117-120 Volts 2,00A @ 117-120 Volts
3,95A @ 100 Volts 3,95A @ 100 Volts 2,15A @ 100 Volts
Mains voltage tolerance range: +/- 10 % +/- 10 % +/- 10 % +/- 10 %
External fuses (anode) 1 x T 630 mA 1 x T 630 mA 1 x T 400 mA
Internal fuses 1 x TT 10 A super slow blow 1 x TT 10 A super slow blow 1 x TT 10 A super slow blow
1 x T 1 A 1 x T 1 A 1 x T 80 m A
Mains fuse (5 x 20 mm)
Europa (variable 220-230 V / 240 V) 1 x 250 V / T 1,6 A 1 x 250 V / T 1,6 A 1 x 250 V / T 1 A
USA/Canada/Asien (variable 100 V / 120 V) 1 x 250 V / T 4 A 1 x 250 V / T 4 A 1 x 250 V / T 2 A
Ambient operating temperature range 0 °C bis + 35 °C 0 °C bis + 35 °C 0 °C bis + 35 °C
10.4 General Mechanical Data Switchblade 100 TSC Head Switchblade 100 TSC Combo Switchblade 50 TSC Combo
Dimensions (including corners, handles, feet)
Width 750 mm 647 mm 600 mm
Height 280 mm 500 mm 500 mm
Depth 258 mm 285 mm 285 mm
Weight 17.6 kg 30.3 kg 22.8 kg
10 Technical Specifications All level indications relate to 0 dBV (1V RMS).
