PAR TS
Unit
Price
PARTS
Number
Description
Quantity
Per
Assembly
Comments
R35
R35
R35
R35
R20
R04
R40
R04
R20
1
1
1
1
2
2
2
1
1
1
1
3
2
16.00
16.00
30.00
30.00
1.50
0.20
0.30
60.00
70.00
175.00
230.00
0.15
2.20
015
015
029
029
061
111
142
H
H
H
H
195
198
10001
10002
10001
10002
10000
10000
10000
abbb
*
F
abbb
*
F
abbb
*
F
abbb
*
F
10000
10000
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Shell Headrest, Graphite
Shell Headrest, Titanium
Moving Support, Graphite
Moving Support, Titanium
Rod, Headrest
Screw, Socket, BTN HD 8-32 x 3/8
Spring Plunger - Headrest
Upholstery, Headrest, Gr. 1 Textile, Foam
Upholstery, Headrest, Gr. 2 Textile, Foam
Upholstery, Headrest, Leather 1, Foam
Upholster y, Headrest, Leather 2, Foam
Scr ew , Pan HD, Hi-Lo T orx #10 x 1/2
Barb Fastener
* Where a = Textile Code (W, V, S, L or P) (see p.49)
Wher e bbb = Color Code (see p. 49)
Note: All part numbers and prices are for single units only.
Headrest Rod Replacement
1. Remove three T20 screws securing the Headrest Cushion to the Headrest Shell.
2. Remove cushion from shell.
3. Slide the Headrest Shell to the highest position in the Moving Support.
4. Remove the two Allen screws on the bottom of the Headrest Rods.
5. Remove the two Barbed Fasteners from the top of the Headrest Rods.
6. Remove Headrest Shell.
7. Slide rods though the Moving Support until the tops are about 10mm into it and stop.
8. Push the new rods against the old rods and drive them though the Moving Support.
**** They must be removed this way so as to keep the Spring Plunger from pushing
though and jamming. ****
9. Re-assemble headrest in the reverse order of steps 6-1.
