AC Power System
• 120VAC version
- Input: 120VAC
- Output: 120VAC pure sine wave, 60Hz
- Continuous output capacity: 150W
- Peak output capacity: 225W
• 230VAC version
- Input: 230VAC
- Output: 230VAC pure sine wave, 50Hz
- Continuous output capacity: 150W
- Peak output capacity: 225W
Battery
• Sealed Lead Acid (SLA)
- 480 W (35 Amp Hour), 12 V output
• Lithium Iron Phosphate
- 45 amp hour
- 12.8 V output
- 2,000 cycles at 80% depth of discharge (DOD)
- 2½ hours recharge time
- Limited 5-year warranty
Battery Level Indicator (BLI)
• Indicates charging status
• Battery level
Recommended Height Adjustment Operation
• 10% Maximum Duty Cycle, 2 minute ON, 18 min OFF
Flat-Panel Display
• Gantry can accommodate accessories weighing up to
11.5kg (25lbs) such as but not limited to flat-panel (1 or 2)
displays, scanners, bottles, etc.
Computer Dimensions
• The T7 work surface can accommodate a computer up to
(L x W x H) 17.35” x 12.3” x 2.25” (440 mm x 312.5 mm
x 57 mm) and has a 16.8” (426 mm) wide opening for a
laptop screen.
USB/ RJ45 Ports are specifically for the connection and use of the following components:
• Barcode Scanner
• External PC
• Mouse
• Printer
Work Surface Bottom View
• Document Scanner
• USB Hub
• Blood Pressure Monitors
• Humanscale Branded Accessories
2.3 TECHNICAL DATA
Keyboard Surface Light
Work Surface Cover
Mounting Holes
Keyboard Frame
Mounting Holes
Work Surface Cover
Mounting Holes
AC Cord Hanger
AC Input
Lifter Mount
Main Power Button
RJ45 Jack
USB Ports
19
