Hunter 30776 - Description of Air Filtration System; Air Purifier Components

42934-01 4
Description of Air Filtration System
Fig. 1 - Illustration of the Air Filtration System
Fig. 2 - Air Purier Components
HEPAtech
®
MAIN
FILTER
FRONT
GRILL
BASE
How the HEPAtech
®
Plus Air Purier System Works
As the air is pulled into the Air Purier, the Pre-Filters capture large particles. Then, the air
travels through the HEPAtech
®
Main Filter where the smaller particles are collected. Odors
are removed as the air passes through the Carbon Odor Filter. Then the Ionizer releases
negative ions into the air that attract positively charged dust, smoke, and pollen particles.
Finally, the clean, puried air is released back into the room.
Dust & Irritants Pollen & Allergens Odors Bacteria Pet Hair & Dander
Carbon
Odor Filter
HEPAtech
®
Filter
99.97% – .1 Microns
Ionizer
PREFILTER ONE ON EACH
SIDE
CARBON ODOR
FILTER
Pre-Filter
Air Purier Components
