Choose Installation Option
For New Construction - attaching to joist go to step A11, page 7
For New Construction - suspended between joists go to step B11, page 9
For Existing Construction - accessible from above go to step C11, page 12
For Existing Construction - accessible only from below go to step D11, page 16
Remove the wiring cover.
Insert the strain relief into the housing and
secure with the washer.
Remove the wiring cover screw.
Pop out the first wiring access slug. Use second if needed.
7
8
9
10
B
